Single inlet medium pressure centrifugal fans with sheet steel casing and impeller.

• Speed: 1320 r/min
• Max. electric power: 0.09 kw
• Max. flow rate: 565 m3/h
• Sound pressure: 58 dB
• Weight: 5 kg

Fan:

• Sheet steel casing.
• Forward curved impeller in galvanized sheet steel.
• Model CMP 38-2M cast aluminum casing.
• Maximum temperature of air to be carried: -25 C +120 C, maximum +100 C model CMP-38.

Motor

• Motors with IE3 efficiency for powers equal to or greater than 0.75 kW, except single-phase, 2-speed and 8-pole.
• Class F motors with ball bearings and IP55 protection except single-phase models with IP54 protection. CMP-38 model with IP21 protection.
• Single-phase 230 V 50 Hz and three-phase 230/400 V 50 Hz (up to 4 kW) and 400/690 V 50 Hz (powers greater than 4 kW).
• Working temperature: -25 C +50 C.

Finish

• Anti-corrosive finish in polyester resin, polymerized at 190 C, after degreasing with phosphate-free nanotechnology treatment.
