Siemens 6SL3246-0BA22-1BA0

Overview

The Siemens 6SL3246-0BA22-1BA0 is the CU320-2 DP control unit designed for use with SINAMICS S120 drive systems. It provides centralized, high-performance control for modular, multi-axis configurations via a PROFIBUS interface, supporting demanding motion control applications.

Key Features

• CU320-2 DP for SINAMICS S120

• PROFIBUS DP communication interface

• Centralized control for multiple axes

• Real-time control of power modules

• Integrated PLC functionality (via optional software)

• High-speed internal communication via DRIVE-CLiQ

• Advanced diagnostics and parameterization

• Compatible with StartDrive and TIA Portal

Technical Specifications

• Siemens Code: 6SL3246-0BA22-1BA0

• Control Type: CU320-2 DP

• Interface: PROFIBUS DP (RS485)

• Communication: DRIVE-CLiQ to power modules and I/O

• Power Supply: 24V DC (external)

• Mounting: Cabinet mounting (booksize format)

• Protection Class: IP20

• Operating Temp: 0C to +50C

• Cooling: Air-cooled

Applications

• Multi-axis machine tools

• Packaging machinery

• Printing and converting systems

• Robotics and automation lines

• Material handling systems

Why Choose Siemens 6SL3246-0BA22-1BA0?

• Centralized high-performance axis control

• Seamless PROFIBUS integration

• Designed for modular SINAMICS S120 systems

• Reliable and scalable motion control

• Backed by Siemens engineering and global support

Order Now

Empower your multi-axis SINAMICS S120 systems with the Siemens 6SL3246-0BA22-1BA0 CU320-2 DP reliable, scalable control at its best.
