Semikron SKM200GB12T4

Overview

The Semikron SKM200GB12T4 is a single IGBT module rated at 200A and 1200V, featuring advanced trench gate technology and housed in the compact SEMITRANS 2 package. It provides efficient switching and conduction performance, making it a reliable solution for medium-to-high power industrial applications.

Key Features

• Voltage Rating: 1200V

• Current Rating: 200A

• Trench and Field Stop IGBT technology

• Integrated anti-parallel freewheeling diode

• Electrically isolated baseplate

• Low switching and conduction losses

• SEMITRANS 2 industry-standard package

Technical Specifications

• Part Number: SKM200GB12T4

• Configuration: Single IGBT with freewheeling diode

• VCE (Max): 1200V

• IC: 200A

• VCE(sat): ~2.0V typical

• Package: SEMITRANS 2

• Baseplate Isolation: 2500V AC

• Mounting Type: Chassis

• Operating Temperature: 40C to +150C

Applications

• AC and DC motor drives

• Inverters and power supplies

• Renewable energy converters

• Industrial heating and welding systems

• UPS systems and automation

Why Choose the SKM200GB12T4

• High efficiency with low switching losses

• Robust performance in industrial environments

• Easy to integrate into existing power systems

• Trusted SEMIKRON build quality

Order Now

The Semikron SKM200GB12T4 IGBT module is available and ships worldwide.
