Semikron SKKT 72/16E

Overview

The SKKT 72/16E from Semikron is a high-performance thyristor/diode module rated for 70A and 1600V. Housed in the industry-standard SEMIPACK 2 package, its designed for demanding power electronics applications requiring high reliability and compact integration.

Key Features

• Thyristor/diode dual configuration

• Blocking voltage: 1600V

• Average current: 70A

• SEMIPACK 2 insulated package

• High surge current handling

• Long-life design for industrial use

Technical Specifications

• Part Number: SKKT 72/16E

• Repetitive Peak Voltage (VRRM): 1600V

• IT(AV): 70A

• Surge Current (ITSM): Up to 1200A

• Insulation Voltage: 2500V RMS

• Package Style: SEMIPACK 2

• Mounting: Screw terminal

• Cooling: Baseplate-cooled

• Operating Temp Range: -40C to +125C

Applications

• Industrial motor control

• AC to DC converters

• Battery chargers

• Welding equipment

• Soft starters and inverters

Benefits

• Compact footprint with high power density

• Easy to mount and connect

• Thermal and electrical robustness

• Proven Semikron reliability

Item available in stock and ready for immediate worldwide shipping.
