Schneider Electric HMIDT551 | Harmony 10.1\” Widescreen HMI

Overview

The Schneider Electric HMIDT551 is a 10.1-inch widescreen HMI (Human-Machine Interface) from the Magelis Harmony series, designed to deliver intuitive control, real-time monitoring, and flexible connectivity for industrial automation systems. With a high-resolution TFT touchscreen, multiple communication ports, and fanless operation, its ideal for machine builders and industrial environments.

Key Features

• Display Size: 10.1\” TFT widescreen touchscreen
• Resolution: 1024 x 600 pixels (WSVGA)
• Touch Technology: Resistive analog touchscreen
• Color Depth: 16 million colors for vibrant visuals
• Communication Interfaces:
  • 2x Ethernet ports (10/100 Mbps)
  • 2x Serial ports (RS232/RS485)
  • 2x USB ports (Host and Mini-B)
• Expandable Storage: SD card slot for data logging and program backup
• Software: Configured with EcoStruxure Operator Terminal Expert (formerly Vijeo Designer)
• Mounting: Panel-mounted with IP66-rated front panel

Technical Specifications

• Model: HMIDT551
• Series: Magelis Harmony / Harmony iPC GXU
• Display Size: 10.1 inches
• Resolution: 1024 x 600 (WSVGA)
• Processor: ARM Cortex-A8 1 GHz
• RAM: 512 MB
• Flash Memory: 512 MB
• Operating System: Embedded Linux
• Power Supply: 24V DC (20%)
• Power Consumption: 13 W max
• Operating Temperature: 0C to 50C
• Humidity: 1090% (non-condensing)
• Protection Rating: IP66 (front), IP20 (rear)
• Dimensions (W x H x D): 271 mm x 213 mm x 56 mm
• Weight: Approx. 2.4 kg

Applications

• Factory Automation: Interface for monitoring and control
• Process Industries: Reliable real-time display
• OEM Machinery: Compact, powerful HMI for machine control
• Utilities & Infrastructure: Remote diagnostics and visualization

Why Choose the Schneider Electric HMIDT551?

• Wide 10.1\” Display: Clear visualization with vibrant color depth
• Multiple Interfaces: Ethernet, USB, and serial ports for flexible integration
• Rugged & Fanless: Industrial-grade design with no moving parts
• Software Ready: Seamless setup with Schneiders EcoStruxure software

Order Now

Fast shipping and worldwide delivery available.
