Schneider Electric ATV930D75N4 | Altivar Process ATV930 Variable Speed Drive

Overview

The Schneider Electric ATV930D75N4 is a 75 kW (100 HP) variable speed drive from the Altivar Process ATV930 series, engineered for demanding industrial applications that require high-performance motor control, energy efficiency, and smart connectivity. Suitable for both asynchronous and synchronous motors, this drive features integrated Ethernet, a built-in EMC filter, and advanced diagnostics and safety features for optimized operation in harsh environments.

Key Features

• Power Rating: 75 kW (100 HP)

• Input Voltage: 3-phase, 380480V 10%

• Motor Types: Asynchronous and permanent magnet motors

• Output Frequency: 0.1 to 599 Hz

• Control Modes:

  • V/f (Voltage/Frequency)

  • Sensorless Flux Vector Control (SFVC)

  • Flux Vector Control with encoder

• Built-in Communications:

  • Ethernet/IP

  • Modbus TCP

  • Embedded Web Server for remote diagnostics

• Integrated EMC Filter: Ensures electromagnetic compatibility

• Safety Feature: Safe Torque Off (STO)

• Energy Monitoring: Real-time tracking of performance and consumption

Technical Specifications

• Model: ATV930D75N4

• Series: Altivar Process ATV930

• Motor Power: 75 kW (100 HP)

• Nominal Output Current: 145 A

• Max Transient Current: 218 A (60 seconds)

• Switching Frequency: Default 4 kHz (adjustable 2.5 to 8 kHz)

• Protection Rating: IP21

• Operating Temperature: -15C to +50C without derating

• Altitude: Up to 1000 m without derating

• Mounting: Wall or panel

• Dimensions (W x H x D): Approx. 315 mm x 745 mm x 310 mm

• Weight: Approx. 54 kg

Applications

• Water & Wastewater: Pumping stations and treatment systems

• HVAC Systems: High-power fans and compressors

• Oil & Gas, Mining: Rugged motor control in harsh conditions

• Industrial Manufacturing: Optimized control for continuous processing systems

Why Choose the Schneider Electric ATV930D75N4?

• High-Power, Intelligent Drive for industrial efficiency

• Built-in Ethernet and Web Access for remote operation

• Advanced Safety and Diagnostics built-in

• Robust and Reliable for demanding environments

Order Now

Fast shipping and worldwide delivery available.
