Schneider Electric ATV930D22N4 | Altivar Process ATV930 Variable Speed Drive

Overview

The Schneider Electric ATV930D22N4 is a 22 kW (30 HP) variable speed drive from the Altivar Process ATV930 series, designed for high-performance motor control in industrial applications. Ideal for energy efficiency, precise control, and IIoT connectivity, this drive supports both asynchronous and synchronous motors operating on a 380480V 3-phase supply.

Key Features

• Power Rating: 22 kW (30 HP)
• Voltage Range: 380480V 10%, 3-phase
• Integrated EMC Filter: Ensures compliance with industrial standards
• Motor Control Modes:
  • V/f (Voltage/Frequency)
  • Sensorless Flux Vector Control (SFVC)
  • Flux Vector Control with encoder
  • Permanent Magnet Motor support
• Output Frequency: 0.1 to 599 Hz adjustable
• Built-in Communications:
  • Modbus TCP
  • Ethernet/IP
  • Embedded Web Server
• Integrated Safety: Safe Torque Off (STO)
• Advanced Diagnostics & Monitoring: Real-time performance and fault tracking

Technical Specifications

• Model: ATV930D22N4
• Series: Altivar Process ATV930
• Motor Power: 22 kW (30 HP)
• Nominal Output Current: 45.2 A
• Max Transient Current: 67.8 A (60 seconds)
• Switching Frequency: 4 kHz default (adjustable 2.58 kHz)
• Protection Rating: IP21
• Operating Temperature: -15C to +50C (without derating)
• Altitude: Up to 1000 m without derating
• Dimensions (W x H x D): 215 mm x 600 mm x 284 mm
• Weight: Approx. 23 kg

Applications

• Water & Wastewater Management: Pumps, blowers, and fans
• HVAC Systems: Compressor and air handler control
• Process Industries: Continuous flow, pressure, and temperature regulation
• Oil & Gas, Mining: Harsh environments with dynamic load conditions

Why Choose the Schneider Electric ATV930D22N4?

• Efficient and Precise Motor Control for demanding applications
• Integrated Ethernet Communication for remote monitoring and diagnostics
• Energy-Saving Operation for variable torque loads
• Robust and Reliable Design built for industrial use
