Omron CJ1W-DA08C | 8-Channel Analog Output Module for CJ-Series PLCs

Overview

The Omron CJ1W-DA08C is an 8-channel analog output module designed for seamless integration with Omron\’s CJ-Series Programmable Logic Controllers (PLCs). It provides precise 420 mA current outputs with a 12-bit resolution and a conversion time of 1 ms per channel, making it ideal for applications requiring accurate analog signal control.

Key Features

• Eight Analog Output Channels: Enables simultaneous control of multiple analog devices.

• Current Output Range: 420 mA per channel.

• High Resolution: 12-bit resolution ensures precise output control.

• Fast Conversion Time: 1 ms per channel allows for responsive system performance.

• Compact Design: Measures 31 mm (W) 90 mm (H) 65 mm (D), optimizing space within control panels.

• Screw Terminal Connections: Facilitates secure and straightforward wiring.

• Seamless Integration: Designed specifically for use with Omron CJ-Series PLCs.

Technical Specifications

• Model Number: CJ1W-DA08C

• Number of Analog Outputs: 8

• Output Signal Range: 420 mA

• Resolution: 12-bit

• Conversion Time: 1 ms per channel

• Output Impedance: Not specified

• Maximum Load Resistance: Not specified

• Power Consumption: 5 VDC, 400 mA max.

• External Power Supply: 24 VDC (inrush current: 20 A max., pulse width: 1 ms min.)

• Dimensions: 31 mm (W) 90 mm (H) 65 mm (D)

• Weight: Approximately 150 g

• Mounting Method: DIN rail

• Operating Temperature Range: 0C to 55C

• Storage Temperature Range: -20C to 75C

• Operating Humidity Range: 10% to 90% (non-condensing)

• Certifications: CE, cULus, NK

Applications

• Process Control: Provides precise current outputs for controlling actuators, valves, and other process control devices.

• Industrial Automation: Facilitates accurate analog signal control in manufacturing and production systems.

• Building Management Systems: Enables control of HVAC systems, lighting, and other building utilities requiring analog input.

Why Choose Omron CJ1W-DA08C?

• High Channel Density: Offers 8 analog output channels in a compact module, maximizing control capabilities without occupying excessive space.

• Precision and Speed: 12-bit resolution combined with a 1 ms conversion time ensures accurate and timely signal output.

• Reliable Integration: Specifically designed for seamless operation with Omron CJ-Series PLCs, ensuring compatibility and ease of use.

• Robust Design: Built to withstand industrial environments with a wide operating temperature range and compliance with international standards.

Order Now

Available for immediate shipping worldwide. Contact us to bundle with Omron CJ-Series PLCs, analog input modules, and other automation components to complete your system setup.
