Bussmann FRN-R-50

Overview

The Bussmann FRN-R-50 is a Class RK5 dual-element time-delay fuse designed to provide reliable overload and short-circuit protection for industrial and commercial applications. With a 50 A current rating and 250 V AC / 125 V DC voltage ratings, this fuse is suitable for power distribution, motor circuits, and general-purpose electrical systems.

Thanks to its dual-element construction, the FRN-R-50 offers a 10-second response time at 500% overload, ensuring tolerance of temporary inrush currents from motors or transformers without nuisance tripping. Its 200 kAIC interrupt rating at 250 V AC guarantees strong fault-clearing capacity, while the ferrule end x ferrule end connection allows easy and secure installation.

Key Features

• Class RK5 dual-element time-delay fuse

• Rated current: 50 A

• Voltage rating: 250 V AC / 125 V DC

• Interrupt rating: 200 kAIC at 250 V AC / 20 kAIC at 125 V DC

• Time-delay response: 10 seconds at 500% overload

• Dual-element design protects against overloads and short circuits

• Connection: Ferrule end x ferrule end

• Fuse indicator: Non-indicating

• Dimensions: 3 in length 0.81 in width 0.81 in height

• Weight: 3.1 lb

• CE Marked for compliance

Technical Specifications

• Manufacturer: Bussmann Series

• Catalog Number: FRN-R-50

• Product Type: Time-delay fuse

• Fuse Class: RK5

• Amperage Rating: 50 A

• Voltage Rating: 250 V AC, 125 V DC

• Interrupt Rating: 200 kAIC (250 V AC), 20 kAIC (125 V DC)

• Response Time: 10 seconds at 500% overload

• Number of Elements: Dual

• Connection Type: Ferrule end x ferrule end

• Fuse Indicator: Non-indicating

• Dimensions: 3 in (L) 0.81 in (W) 0.81 in (H)

• Weight: 3.1 lb

• Compliance: CE Marked

• Packaging Type: Standard

Applications

• Motor protection circuits

• Transformer protection

• Power distribution panels

• Industrial machinery

• Commercial electrical systems

Why Choose the FRN-R-50

• Handles high inrush currents with time-delay dual-element design

• High 200 kAIC interrupt rating ensures maximum protection

• Reliable overload and short-circuit protection for industrial systems

• Compact, ferrule-type connection for easy installation

• Trusted Bussmann quality with CE compliance

Order Now

The Bussmann FRN-R-50 Class RK5 Fuse is available and ships worldwide.
