AllenBradley 1326ABB515E21

Overview

The AllenBradley1326ABB515E21 is a high-performance Torque Plus AC servo motor, rated at 460V and delivering 10.4Nm continuous torque at 3000RPM. Featuring resolver feedback, a robust IP65-rated housing, and a compact 149mm frame, it is engineered for demanding motion control systems. Though discontinued, it remains ideal for legacy 1394, Kinetix, and Ultra3000 drive platforms.

Key Features

• Three-phase, 460V AC input

• Continuous torque: 10.4Nm

• Stall-rated torque: 10.4Nm (zero RPM)

• Rated speed: 3000RPM

• Resolver feedback (2048ppr via resolver-to-encoder)

• IP65-standard housing (with optional shaft seal)

• Rugged aluminum housing with high thermal performance

• IEC metric flange with keyway

• UL-recognized insulation system

• Vertical mounting allowed shaft up/down

• Built-in thermal switch for overload protection

Technical Specifications

• Model: 1326ABB515E21

• Voltage Rating: 460/380V AC

• Continuous Torque: 10.4Nm

• Peak Stall Torque: 31.2Nm

• Rated Speed: 3000RPM

• Rated Power: 2.3kW

• Frame Size: 149mm diameter

• Feedback Type: Resolver-based (2048ppr)

• Enclosure Protection: IP65 (with shaft seal)

• Mounting Type: IEC metric flange with keyway

• Weight: ~21.2kg (46.65lb) (Radwell International, Rockwell Automation, Industrial Automation Co., elwood.com, DO Supply, Shenzhen Wisdomlong Technology CO.,LTD)

• Insulation Class: UL-recognized

• Peak Stall Current: up to 18.3A (DO Supply)

Applications

• CNC machines and axes

• Robotics and automated pick-and-place systems

• Packaging and handling lines

• Motion control platforms (Allen-Bradley 1394, Ultra3000, Kinetix)

• Industrial automation with high torque requirements

Why Choose the 1326ABB515E21

• High torque capacity for precision applications

• Resolver feedback ensures accurate and reliable motion control

• Rugged and compact design with IP65 protection

• Compatible with legacy and current Allen-Bradley servo systems

• Discontinued, yet still widely stocked for legacy support

Order Now

The AllenBradley1326ABB515E21 servo motor is available via surplus and refurbish channels. Ideal for servicing or upgrading existing motion control systems.
