Allen-Bradley 20-750-ENC-1 | Single Incremental Encoder Input Module for PowerFlex 750 Drives (5V DC)

Overview

The Allen-Bradley 20-750-ENC-1 is a single incremental encoder input module designed for use with PowerFlex 750-Series AC drives, including PowerFlex 753 and 755. It supports 5V DC differential or single-ended encoder signals, providing accurate speed and position feedback for closed-loop motor control applications.

This module enables high-performance motion control and position regulation, making it ideal for applications that require precise encoder feedback, such as conveying, winding, packaging, and printing systems.

Key Features

• Supports Single Incremental Encoder Input

• Voltage Range: 5V DC (differential or single-ended)

• Designed for PowerFlex 750-Series Drives PowerFlex 753 and 755

• Accurate Speed and Position Feedback Enhances control precision

• DIN Rail or Panel Mount Mounts directly in drive

• Plug-and-Play Installation Easily configured in Studio 5000 or DriveTools

• Ideal for Closed-Loop Control Systems

Technical Specifications

• Catalog Number: 20-750-ENC-1

• Encoder Type: Incremental

• Input Voltage: 5V DC

• Signal Type: Differential (RS-422) or single-ended

• Mounting: Directly into PowerFlex 750 drive option slot

• Compatibility: PowerFlex 753, PowerFlex 755

• Operating Temperature: 0C to +50C

• Configuration Tools: Studio 5000, DriveTools SP

• Use Case: Closed-loop vector control and position regulation

Applications

• Winding and Unwinding Machines

• Printing and Packaging Lines

• Material Handling and Conveyors

• Textile, Automotive, and Food Processing

• High-Precision Motion Control

Why Choose the 20-750-ENC-1?

• Reliable feedback for encoder-based control

• Simple integration with PowerFlex 750 drives

• Improves accuracy and performance of closed-loop systems

Order Now

Available and ready for global shipping.
