Allen-Bradley 1769-OB32 | 32-Channel 24V DC Sourcing Output Module Compact I/O Series

Overview

The Allen-Bradley 1769-OB32 is a 32-point digital output module designed for CompactLogix and MicroLogix 1500 systems, offering 24V DC solid-state sourcing outputs. With high-density output capability in a compact form factor, this module is ideal for applications requiring space-saving and efficient control of discrete field devices.

Each output can handle up to 0.5 A, and the module is split into two groups of 16 channels, allowing flexible power distribution and I/O segregation.

Key Features

• 32 Digital Outputs 24V DC sourcing type

• High-Density Design Saves panel space and wiring

• Solid-State Outputs Fast response and long life

• Group Isolation 2 groups of 16 outputs each

• DIN Rail or Panel Mountable Easy installation with CompactLogix chassis

Technical Specifications

• Catalog Number: 1769-OB32

• Series: Compact I/O

• Output Type: Digital sourcing (24V DC)

• Number of Outputs: 32 (2 groups of 16)

• Output Current: 0.5 A max per channel, 4 A max per group

• Voltage Range: 1030V DC

• Mounting: DIN rail or panel mount

• Compatible Platforms: CompactLogix, MicroLogix 1500

• Operating Temperature: 0C to +60C

• Weight: Approx. 400 g

Applications

• Machine Control Panels Discrete control of solenoids, relays, lights

• OEM Systems High I/O density for compact machines

• Distributed Control With CompactLogix or MicroLogix systems

Why Choose the 1769-OB32?

• High point count reduces module count and space

• Reliable solid-state outputs for high-speed switching

• Flexible use across CompactLogix and MicroLogix platforms

Order Now

In stock and ready to ship worldwide. Perfect for expanding your Compact I/O system with reliable 24V DC sourcing outputs.
